GBX Gravel Box

Burchland Manufacturing creates quality boxes to transport gravel. The bedding boxes are built with protective strips to add strength and make them last. Perfect for construction sites, we manufacture equipment that will increase the speed of completing projects.

The floors and ends of our boxes are built with a 1/2″ plate. Tear strips are placed on the floor of the bedding box which increases the strength and helps to prevent wear. The formed wear strips located on the bottom of the dump box help prevent plowing while also adding strength and durability. The sides of the GBX Gravel Box are made from a 3/8″ plate and the heavy wall 3″ x 4″ tubing on the sides and ends prevents flexing and punctures.

The grabber tube is an 8″ sch. 80 pipe. Gussets run the entire length of the grabber arm for extra strength. Heavy-duty lift points come standard and make an excellent tie-down point for transport.

Features:

— High-quality gravel boxes that are durably built to handle the wear and tear of heavy equipment on construction sites.

— Our bedding material containers help to reduce waste and increase speed on the job site.

— Tear strips are placed on the floor of the bedding box which increases the strength and helps to prevent wear.

Contact us today to learn more!

The LGX Burchland Laser Grader

The LGX Burchland Laser Grader is a first of its kind to the skid steer grading market. This is not your everyday box blade or skid steer grader attachment. This innovative attachment can be configured in many different ways and all from the operator’s seat.

The versatile precision grading attachment has the capability to be controlled by: Laser, GPS, Total station, and Sonic tracer. The versatility in control system allows the owner to purchase any of the major brand machine controls and have it performed with great precision. The unique rear-mounted support roller on this attachment allows the blade to be supported between the skid steer and the cut which will create a smooth grade. This system allows the operator to push fill into corners and changes in elevation, all while maintaining a precise grade. This benefit saves time and labor by not having to manually fill corners by hand, like the competitors models.

Standard Features:

  • Universal skid steer mount
  • Laster, GPS, and Total Station Sonic tracer and string line capable
  • Available in 7’, 7’6” and 8’ blade width
  • Mid-mounted stabilizing roller
  • Can be operated in auto or manual mode
  • 25 degree hydraulic blade rotation each direction
  • 270 degree hydraulic wing rotation

The LGX Burchland Laser Grader is a highly durable grader/box blade that delivers a precise grade on many different styles or jobsite. This grader can be found prepping subgrade for parking lots, streets, highways, athletic fields, driveways, and any other job that requires a precise grade. This hybrid grader allows the operator to independently and hydraulically rotate the end plates 270 degrees, from folded directly behind the blade to all the way straight forward transforming the grader blade into a box blade.

The LGX Burchland Laster Grader is proven to be a reliable attachment for finishing grading. You will achieve a flatter, more consistent grade while accelerating your grading projects. The grader/box blade is one of the highest performing grading systems available for skid loaders allowing maximum production. The unique design will give the operator exceptional control of the grade and the multiple configurations available with the attachment.

We’d be happy to answer any questions you may have about this product or any other product we carry. Please feel free to contact us today!

AGT Auto Grading Soil Trimmer

Trim, Grade and Roll all in One Pass

The Burchalnd Auto Grading Trimmer is a skid steer mounted trimmer designed for site work and concrete contractors looking for a perfectly graded job site.

A Superior Grading Solution

The Burchland AGT soil skid steer attachment is ideal for trimming sub-grade soil under building pads, parking lots, curbs and gutters, sidewalks, trails, and roads. The AGT works well on job sites where a large road trimmer would not be practical. The versatility of the AGT Soil Skid Steer Trimmer allows it to easily handle job sites with varying grades and slopes like a parking lot with multiple drainage areas and islands.

The AGT features an innovative automatic control system that follows a 3-D CAD-designed surface, within sub-centimeter accuracy. Once a 3-D CAD surface file is uploaded to the machine controls, the skid steer trimmer will follow that surface grade precisely. The AGT can be outfitted with string line controls, single and dual slope laser controls, as well as all forms of 3-D surface grading systems, including Robotic Total Station. Trimmer can also be operated in manual mode.



Contact us or watch our video to learn more about the Burchland Auto Grading Trimmer!

BR2 Blanket Roller

The Burchland Manufacturing Blanket Roller2 is an erosion control productivity tool that can save hundreds of hours installing erosion control blankets and matting of all types. It can also be used for other rolled materials such as non-woven geotextiles, straw blankets, and geo-grids. Able to unroll any type of material with or without a center core. This labor-saving erosion control device can cut your man hours and double your productivity at the same time. The hydraulic grapple arm on this unit is operated from the seat allowing the operator to back up to a roll of material and load it without the need for additional labor. This saves labor time and money. Learn more or give us a call today! 641-316-9486

Key Features:

— This labor-saving erosion control device can cut your man-hours and double your productivity at the same time.

— Can be used for other rolled materials such as non-woven geotextiles, straw blankets, and geo-grids.

— The hydraulic grapple arm on this unit is operated from the seat allowing the operator to back up to a roll of material and load it without the need for additional labor.

BR2 Specifications:

Max roll width: 17’

Max roll weight: 500lbs

Transport width: 101’’

Overall height: 49’’

Overall length: 52’’

Total weight: 1,490lbs



Watch our video to learn more about the Burchland Manufacturing Blanket Roller2!

EZR Material Roller

Your workday just got a lot easier. Introducing the Burchland EZR Material Roller. Precisely crafted and ruggedly built, the Burchland EZR will not only lighten your load-but cut your crew requirements by 1 Pivot Arm locks for – storage or transport. C almost half. From loading to unloading the flat-bed to laying down roll 3-b f , -, after roll, any project will get done faster with less physical effort with rl Pivot Arm adjustable stop the EZR. Take a look at some of the features that make the Burchland allows for below horizontal EZR a product whose time has come. Learn more or give us a call today! 641-316-9486

Key Features:

  • This labor-saving erosion control device can cut your man-hours and double your productivity at the same time.
  • Can be used for other rolled materials such as non-woven geotextiles, straw blankets, and geo-grids.
  • The hydraulic grapple arm on this unit is operated from the seat allowing the operator to back up to a roll of material and load it without the need for additional labor.

Cut material installation costs by as much as 40%… Or more with the Burchland EZR Material Roller!

Applications Include:

  • Highway mediums shoulders, channel bottoms, and slide slopes.
  • Golf courses, fairways, roughs
  • Residential, commercial, and industrial developments
  • Landfill caps and slide slopes
  • Mine reclamation projects
  • Pipeline right-a-ways and more!

Watch our video to learn more about the Burchland EZR Material Roller!

SCX Straw Crimper

Burchland’s ALL NEW SCX Straw Crimper lets you say good-bye to poorly secured, uneven straw installation due to rocks, roots, stumps—and even sidewalks. Why? Because each SCX straw crimper disc can pivot left and right and up and down—independently from each other. No other crimper offers this time saving, quality installation feature. When a conventional single-shaft crimper hits a rock, the whole shaft lifts up and can totally disengage the soil. Not so with the SCX. When an SCX disc hits an object, it floats over or pivots around it, while the other discs remain firmly engaged with the soil. The disc pivoting action also allows for smoother, tighter turns for faster installation. These features along with the SCX’s sturdy construction and ease of operation let you confidently and uniformly crimp straw—that will stay crimped—to keep soil in place and undisturbed… even in high winds or heavy rainfall. Learn more or give us a call today! 641-498-2063

Key Features:

— Spring loaded independent disc suspension smooths out any ground condition.

— Heavy gauge tubular frame stands up to the toughest conditions.

— Rock Guards prevent damage to bearing hubcaps.

— Pivoting coulter assembly with heavy-duty, heat-treated, spring-loaded notched discs, prevents rocks from wedging between discs.

— 8″ disc spacing is standard with other disc spacing available.

Watch our video to learn more about the SCX Straw Crimper!

#1 Silt Fence Installer

Burchland manufactures erosion control products including a Silt Fence Installer, a Material Roller, and Material/Rock Boxes. This established company also has new products on the way and is excited to continue sharing their unique and quality manufacturing products to their customers. Burchland Manufacturing Inc. is proud of the fact that they design, engineer, and manufacture quality equipment that users designate as productivity tools. This company truly strives to provide equipment for applications that make the workday easier, more productive, and more profitable. Delivering efficient solutions for erosion control and other industry applications is what Burchland Manufacturing Inc. does best!
